Corevital APB Filters
Gamma Stable Filters for Sterile Filtration of Air and Gas

CorevitalTM APB capsule filters incorporated with hydrophobic PVDF membrane are especially designed for the sterile filtration of air and gas. These filter capsules provide high air flows and 100 % removal of bacteria from air and gases, even in the presence of high humidity and moisture. CorevitalTM APB Gas filter capsules could be integrated within gamma-irradiatable or gamma-sterilized complex systems such as biorectors, or transfer sets where venting is required.

Features and benefits

  • Compact design,easy to handle and installation
  • Highly-retentive for sterility safety
  • Available in multiple formats

Applications

  • Biocontainers
  • Fermentation inlet air
  • Transfer sets

Available Formats

  • MiniventTM capsule filters
  • BricapTM C capsule filters, BricapTM L capsule filters, BricapTM T capsule filters
  • Cobetter filter cartridge
  • Specifaction

For technical data sheet or application inquiry, you are more than welcome to contact our sales representative by sales@cobetterfilter.com or leave a message

Specifications

Filter MediaHydrophobic polyvinylidene fluoride (PVDF)
Pore Size0.2μm
Filter Structure ComponentsGamma Stable Polypropylene
Max. Temperature50℃
Max. Differential Pressure
Forward, @ 25℃
2.4bar|34.8 psig
Bubble Point @ 20℃≥ 1.1 bar | 16 psig in 60% isopropanol (IPA) 40% water, Air
Bacterial RetentionRetention of 107 CFU/cm2 Brevundimonas diminuta (ATCC®19146) according to ASTM F838.
Sterilization Method-Gamma Irradiation: 25 kGy (recommended)-50 kGy (max.), 1 Sterilization Cycle
-Autoclave: Max. 20 cycles at 131 °C for 30 min. (Cannot be steam sterilized in-line)
Bacterial Endotoxin<0.25EU/mL, according to LAL Test, USP <85>
Component Material ToxicityMeet the criteria of the USP<88>Reactivity Test for Class VI-121 °C plastics.
Quality AssuranceThese products are manufactured in a facility which adheres to ISO 9001:2008 Practices.
